    Re: Import Motor FAQ - Long Stroke Mills

    Quote Originally Posted by brettt
    got a loncin 125

    says 123 on cylnder

    bore 52.5 stroke 67.5

    pin hole 14 to piston top (flat piston)

    14 pin

    cyl height 69

    intake 23

    exhaust 19

    is this a 120?monster?

    bought a 138 kit from china the bottom of cylnder doesnt fit in the case hole

    and the studs are spaced different

    can i mod the cyland cace to fit or is it wrong

    china guy told me its for ducar 125

    also got inner rotor cdi light oil slinger works sweet rev-o-matic


    Maybe you measured the stroke wrong or typed it in wrong. That would give you a 146cc engine. If it was 57.5 then you would have 124cc.
    That's right, he said "nappy headed hoes."

  2. #32
    Junior Member
    This user has no status.

    brettt's Avatar

    Join Date
    Jun 2007
    Posts
    4

    Re: Import Motor FAQ - Long Stroke Mills

    sorry the stroke is 55 mabey 55.5

    con rod is 88 from crank round to top of con rod

    con rod says xie ma 110-2

    im assuming you measure cylnder for bore not piston?

  3. #33
    Senior Member
    is I only do 2 things , Ride Dirt
    Bikes and Wanting to Ride Dirt
    bikes !!

    T Bolt USA's Avatar

    Join Date
    Jan 2005
    Location
    Pennsylvania
    Posts
    10,265

    Re: Import Motor FAQ - Long Stroke Mills

    Quote Originally Posted by brettt
    got a loncin 125

    says 123 on cylnder

    bore 52.5 stroke 67.5

    pin hole 14 to piston top (flat piston)

    14 pin

    cyl height 69

    intake 23

    exhaust 19

    is this a 120?monster?

    bought a 138 kit from china the bottom of cylnder doesnt fit in the case hole

    and the studs are spaced different

    can i mod the cyland cace to fit or is it wrong

    china guy told me its for ducar 125

    also got inner rotor cdi light oil slinger works sweet rev-o-matic


    the one thing that is questionable is 69mm tall cly ,,,,the monster /gpx is 78mm



    we just had a customer with a loncin that the tb146cc would not fit due to small case hole
    T Bolt USA - Let's go riding!

    All the top Pit Bikes, Engines and Parts for Pit bikes & Minis! Let us know if we can help!

    Hidden Content - Hidden Content - Hidden Content - Hidden Content - (704) T-BOLT-US - Skype: TBoltUSA

  4. Remove Advertisements
    PlanetMinis.com
    Advertisements


  5. #34
    Senior Member
    This user has no status.

    RcWannabe's Avatar

    Join Date
    May 2006
    Location
    Erie, Pa
    Posts
    7,433

    Re: Import Motor FAQ - Long Stroke Mills

    Quote Originally Posted by jkline805
    hey i have the same Lifan big valve with the 124cm3 on the cylinder that turned out to be a 52.4x55mm, but the funny thing is, my engine # is 156FMI. I dont think that you can trust any of the markings on the cylinder and apparently not the model # either. oh well.


    Mine is the same way, the later 2006 Rcm bikes Lifan motors have the 1*56*FMI marking with 124cc on the cylinder but they are in fact a regular old monster lifan 120 with 52.4x55.5.
    Founder of the Fl Mullisha....Pa Chapter

  6. #35
    Junior Member
    This user has no status.

    brettt's Avatar

    Join Date
    Jun 2007
    Posts
    4

    Re: Import Motor FAQ - Long Stroke Mills

    got a title with the bike says 9.8hp?

    could this be correct

    do you measure cyl from gasket to gasket or include the tongue into case

    mine was based on gasket to gasket

  7. #36
    Junior Member
    This user has no status.

    GeoB's Avatar

    Join Date
    May 2007
    Posts
    10

    Re: Import Motor FAQ - Long Stroke Mills

    Quote Originally Posted by Z50King
    the last three numbers on the top row,

    FAH or FMH

    A = automatic clutch

    M = manual clutch

    i dont think anyone knows what F or H mean


    I was just given a mystery engine with the eng# HS1P47FMD

    *350J1662*



    It is definitely an auto clutch.



    GeoB

  8. #37
    Banned
    This user has no status.

    firepower354's Avatar

    Join Date
    Oct 2006
    Location
    Flint MI
    Posts
    0

    Re: Import Motor FAQ - Long Stroke Mills

    Quote Originally Posted by firepower354
    Has anyone compiled a list of the con rod and crank pin specs on the Chinese motors? I'm looking to do some parts swapping.....


    Anything yet?

  9. #38
    Senior Member
    This user has no status.

    Kurlon's Avatar

    Join Date
    Feb 2005
    Location
    Southern Maine
    Posts
    8,601

    Re: Import Motor FAQ - Long Stroke Mills

    I don't recall the thread, but the Jialing 125 and Lifan 120 pin sizes got posted, other than that I've not seen anything.

  10. #39
    Senior Member
    This user has no status.

    boonacka's Avatar

    Join Date
    Mar 2006
    Posts
    1,592

    Re: Import Motor FAQ - Long Stroke Mills

    I bought a motor from Fatcaat last year and he told me it was a Jialing 120. I put in a 131 bbk a while ago with the help of Vince from Tbolt. I remember it starting out at 52.5 x 55.5 with a 27/23 head with long anti-kickback cam, 13mm wristpin, and Honda stud spacing. Dont know how much info you have on this motor

  11. #40
    Senior Member
    This user has no status.

    fatcaaat's Avatar

    Join Date
    Sep 2004
    Location
    Arlington, VA
    Posts
    5,478

    Re: Import Motor FAQ - Long Stroke Mills

    Quote Originally Posted by boonacka
    I bought a motor from Fatcaat last year and he told me it was a Jialing 120. I put in a 131 bbk a while ago with the help of Vince from Tbolt. I remember it starting out at 52.5 x 55.5 with a 27/23 head with long anti-kickback cam, 13mm wristpin, and Honda stud spacing. Dont know how much info you have on this motor


    This may actually be an early model of the "Xtreme" motors or a Jialing. Either way, this motor is the one to build up once you fix the tranny issues...which, of course I did before I sold it.



    I don't believe it had 27/23 valves...I think it had 25/22 valves in it, which are big for that style and stud spacing.



    And, like I always say about this motor...keep me in mind when it is worn out and you need a new one!

  12. #41
    Senior Member
    This user has no status.

    boonacka's Avatar

    Join Date
    Mar 2006
    Posts
    1,592

    Re: Import Motor FAQ - Long Stroke Mills

    Your right it was 25/22. Well with the 131, VM26, G2 cam and mild porting, this motor feels like a beast. I swapped out the shiftstar with the "fixed" shiftstar from SDG and now no more mis shifts.



    I'll sell you this motor back if you have a lifan 120 monster i can buy from you.

  13. #42
    Senior Member
    This user has no status.

    mattmoto441's Avatar

    Join Date
    Sep 2004
    Location
    unknown
    Posts
    2,236

    Re: Import Motor FAQ - Long Stroke Mills

    Here are the specs that came with our Lifan WIN138.



    1P55FMJ-2E10

    Displacement: 140ml

    Bore×Stroke: 55mm×59mm

    Max.Power & Rotating Speed: 8.0kw/7500r/min

    Max.Torpue & Rotating Speed: 9.5N.m/5000r/min

    Min.Fuel Consumption: ≤367g/kw.h

    idling Speed: 1500r/min

    Ignition: CDI

    Lubrication: Pressure/splash

    Transmission: 4 speed

    Not sure how to read their power ratings and convert it to HP , and TQ figures that make sense ?

    I will try and get a picture of it.

  14. #43
    cz2
    cz2 is offline
    Senior Member
    This user has no status.

    cz2's Avatar

    Join Date
    Apr 2007
    Posts
    128

    Re: Import Motor FAQ - Long Stroke Mills

    lets keep this thread going with specs on new 140 lifan, 150yx. and mods, parts that fit or same, add to front of this thread. can leave out some unimpott b.s. like this. ogm race 140 mikuni 24mm [mine came with 22] but 24 manifold. comp 10:1 bore 55mm stroke59mm intake 27mm ex 23mm, n-1-2-3-4 clutch 4 disc final drive0.196 11hp piston pin? cylinder hight 83cm countershaft 17cm 6 splines. cam?

  15. #44
    Member
    This user has no status.

    CCSRacer197's Avatar

    Join Date
    Jan 2008
    Location
    Vineland, NJ
    Posts
    83

    Re: Import Motor FAQ - Long Stroke Mills

    long stroke mills rule....my 2 cents

  16. #45
    Junior Member
    This user has no status.

    lamby's Avatar

    Join Date
    Jan 2008
    Posts
    3

    Re: Import Motor FAQ - Long Stroke Mills

    hey guys, im new to this site. maybe it's been beat to death, but which company would you guys reccommend? reliability wise? thanks!
